B1 regulator rectifier

Home Forums All Things 750 Twin Lonesome memories B1 regulator rectifier

Tagged:

Viewing 6 posts - 1 through 6 (of 6 total)
  • Author
    Posts
  • #26333
    leejohn
    Participant

    Hi. Need some help with my replacement regulator rectifier. Need a new one and all on eBay are 1 phase.

    mine has the seven wires but no markings to order another. Went to m&p and they sent me single phase which is no good. They can help but asked if I can get some numbers off another.

    Anyone have the upgrade with seven wires with any model number on it?

    Thanks.

    Lee.

    #26335
    Kaptainkwak
    Keymaster

    Is this what you are after?

    Buy Regulator/Rectifier

    #26337
    leejohn
    Participant

    Hi Andy. Went to m&p and they sent wrong one.

    looks like that one would do but do you have any lettering or markings on it. They said they need something to go on.

    they said the one they sent me is what they have to fit mine. It’s 1 phase so no good.

    Thanks.

    Lee.

    #26348
    Kaptainkwak
    Keymaster

    I rang M&P and convinced them that what they were offering was incorrect. They put me onto their supplier ELECTREX WORLD who I also have rung. Unfortunately they only have skeleton staff at the moment and I have not yet been successful in ringing when there is someone who can give me technical help. I will keep trying mate

    #26357
    Kaptainkwak
    Keymaster

    I have finally manged to make contact with Electrex world.

    The regulator you require is their RR33 Regulator/Rectifier. You will probably notice the combined unit has 7 wires whereas the original units only had 6 wires. Also the plug configurations are different. None of this matters technically but you will need to modify as follows.

    The original Rectifier has 3 yellow wires, one for each phase. These need to be connected to the 3 white wires from the combined unit. There is no specific order.

    The Green, Brown and Black wires on the combined unit connect to the Green, Brown and Black wires where the Original regulator plugged into the main wiring Harness.

    You will now be left with a single Red wire, the extra 7th wire. This needs to be connected to the Battery Positive either directly or into a positive line in the main wiring harness.

    In summary the 3 white wires are for the 3 phases of charging. The Green and Brown wires are for the Field Coil and the Black and Red wires are for the Battery.

    KK

    #26544
    leejohn
    Participant

    Hi KK

    Thanks for the wiring details. Still gonna need a new unit so it’s very much appreciated.

    Thanks

    Lee.
